Stäubli

Reliable Connection Technology for Accurate Measurements

Stäubli Electrical Connectors is a global leader in safe and high-quality test accessories. With over 40 years of experience, the company offers a comprehensive range of insulated test accessories that meet, and often exceed, the strictest international safety standards. These solutions are essential for accurate and secure measurements in various applications, including laboratories, industrial installations, and power electronics environments.

Innovative Test and Measurement Solutions

Stäubli’s Test & Measurement portfolio includes high-performance accessories designed for maximum reliability, safety, and precision. The product range features:

  • Insulated test leads and measurement probes – for safe and stable connections
  • Crocodile clips and test probes – for versatile and precise measurement tasks
  • High-frequency measurement accessories – suitable for applications from DC to high-frequency signals
  • Highly flexible wires – heat-resistant and ideal for various testing environments

With patented MULTILAM contact technology, these accessories ensure low contact resistance and long service life, even under intensive use.

Stäubli test accessories are used worldwide across diverse sectors, including electronics workshops, educational institutions, power electronics, and industrial facilities. Whether you’re performing precision lab work or diagnostics in demanding environments, Stäubli provides solutions you can rely on.


Why Choose Stäubli Test Accessories?

  • Safety first: Products meet and exceed the highest international safety standards
  • Reliable performance: Consistent results even under demanding conditions
  • Ongoing innovation: Continuous product development to meet evolving industry needs
  • Global support: Available in over 28 countries with local expertise and service

With decades of experience and a strong commitment to innovation, Stäubli delivers safe, reliable, and high-quality test solutions trusted by professionals around the world.

Stäubli
3879 Products
4 mm BNC-adapter black - XM-BB/4 black
XM-BB/4 black 4 mm BNC-adapter black - XM-BB/4 black
Two-pole touch-protected adapter with Ø 4 mm connectors linked to the BNC system. Version with BNC male and rigid Ø 4 mm sockets, accepting Ø 4 mm plugs with rigid insulating sleeve. The contact pin of the inner conductor of the BNC connector is in gold-plated brass.
€27.50 per item
67.9756-05028 67.9756-05028
€42.10 per item
67.9756-10021 67.9756-10021
€47.10 per item
67.9756-10028 67.9756-10028
€47.10 per item
67.9756-20021 67.9756-20021
€57.00 per item
67.9756-20022 67.9756-20022
€57.00 per item
4 mm adapter blue - A-SLK4-S blue
A-SLK4-S blue 4 mm adapter blue - A-SLK4-S blue
Adapter, made of brass can be screw-mounted into Ø 4 mm sockets. The expandable Ø 4 mm plug of this adapter can be locked into the socket by tightening the grub screw. Assembled, the adapter offers complete touch-proof protection. Ø 4 mm rigid socket in insulator accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve.
€4.70 per item
4 mm adapter red - A-SLK4-RS red
A-SLK4-RS red 4 mm adapter red - A-SLK4-RS red
Insulated, with M3.5 external thread for connecting to rail mounted terminals with M3.5 threaded holes. Machined brass. Ø 4 mm rigid socket in insulator accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Socket with internal slot for screwdriver.
€2.90 per item
4 mm adapter blue - A-SLK4-RS blue
A-SLK4-RS blue 4 mm adapter blue - A-SLK4-RS blue
Insulated, with M3.5 external thread for connecting to rail mounted terminals with M3.5 threaded holes. Machined brass. Ø 4 mm rigid socket in insulator accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Socket with internal slot for screwdriver.
€2.90 per item
4 mm safety test clip red - SKPS-4 red
SKPS-4 red 4 mm safety test clip red - SKPS-4 red
With flexible shaft and spring wire grabber (stainless steel) for a good contact to pins and wires in inaccessible places. Especially suitable for measuring voltages. The shaft is silicone insulated and guarantees good heat resistance and flexibility even at low temperatures. Ø 4 mm rigid socket in handle accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve.
€19.20 per item
4 mm safety probe black - SPP4-S/F black
SPP4-S/F black 4 mm safety probe black - SPP4-S/F black
Spring-loaded stainless steel needle which reacts resiliently under light pressure. Specially suited for sensitive printed circuits. Test probe with handle guard chamfered on both sides. Ø 4 mm rigid socket in handle accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Supplied with protective cap.
€32.00 per item
SCHK-SPP4 transparent Protective cap transparent - SCHK-SPP4 transparent

Discontinued

Details
2 mm safety probe black - SPP2-S black
SPP2-S black 2 mm safety probe black - SPP2-S black
With tapered, stainless steel rigid needle. Handle guard chamfered on both sides. Ø 2 mm rigid socket in handle accepting spring-loaded Ø 2 mm plugs with rigid insulating sleeve. Supplied with protective cap.
€10.00 per item
MB2 Assembly mandril - MB2
€6.80 per item
MB2-S NI Assembly mandril - MB2-S NI
€19.40 per item
Adapter lead 15 cm black - AK205/405-BK black
AK205/405-BK black Adapter lead 15 cm black - AK205/405-BK black
Highly flexible. One end with Ø 2 mm stackable MULTILAM plug, the other end with Ø 4 mm rigid socket with rigid insulating sleeve.

Discontinued

Details
Adapter lead 15 cm red - AK205/405-BK red
AK205/405-BK red Adapter lead 15 cm red - AK205/405-BK red
Highly flexible. One end with Ø 2 mm stackable MULTILAM plug, the other end with Ø 4 mm rigid socket with rigid insulating sleeve.

Discontinued

Details
LK1-A red - 15 cm 1 mm connecting lead 15 cm red - LK1-A red
€10.80 per item
LK1-A black - 30 cm 1 mm connecting lead 30 cm black - LK1-A black
€11.10 per item
2 mm connecting lead 15 cm black - LK2-F black
LK2-F black - 15 cm 2 mm connecting lead 15 cm black - LK2-F black
Highly flexible with stackable Ø 2 mm hollow plugs on both ends.
€8.10 per item
