IEC Connector Snap Fit To Panel Twin Fused Inlet PF0033 Series 3mm Panel 6.3mm Tab Termination EN60 320-1 Standard Sheet C14 Class I
€5.98*
Prices excl. VAT plus shipping costs
Article number:PF0033/30/63
Manufacturer number:PF0033/30/63
Brand:Bulgin
Minimum order quantity:20
Datasheet (EN)Specifications
| approvals: | CSA, UL |
|---|---|
| body_material: | Nylon 66 |
| current_max: | 10A |
| flamability_rating: | UL94V-0 |
| function: | Panel Mount Fused Connector |
| iec_connector_mates_with: | PX0587,PX0587/SE,PX0588 |
| iec_en60620_type: | EN60 320-1 Standard Sheet C14 Class I |
| max_operating_temperature: | +70°C |
| max_panel_thickness: | 3mm |
| min_operating_temperature: | -20°C |
| min_panel_thickness: | 3mm |
| number_of_contacts: | 3 Contacts |
| rohs_compliant: | |
| uniek_nr: | blgPF0033/30/63 |
| voltage_max: | 250V |
