3 POLE SHROUDED PLUG
€7.41*
Prices excl. VAT plus shipping costs
Article number:PX0686
Manufacturer number:PX0686
Brand:Bulgin
Minimum order quantity:15
Downloads
Datasheet (EN)Specifications
| approvals: | CSA, ENEC, UL, VDE, RCM, CCC |
|---|---|
| body_material: | Nylon 66 |
| current_max: | 10A |
| flamability_rating: | UL94V-0 |
| function: | Straight Male Connector |
| iec_connector_colour: | Black |
| iec_connector_mates_with: | PX0675,PX0695,PX0578,PX0783,PX0793,PX0793/1,PX0716,PX0717,PX0718 |
| iec_en60620_type: | EN60 320-2-2 Standard Sheet E Class I |
| max_operating_temperature: | +70°C |
| min_operating_temperature: | -40°C |
| number_of_contacts: | 3 Contacts |
| uniek_nr: | blgPX0686 |
| voltage_max: | 250V |
