2.4mm Jack to 3.5mm Plug RF Adapter
€156.54*
Article number:RFAA240J350P
Manufacturer number:RFAA240J350P
Brand:Bulgin
Minimum order quantity:1
a27e3f0172e92acc4ae5edb208992313Specificaties
| body_length: | 21.80mm |
|---|---|
| body_material: | Stainless Steel Passivation |
| centre_contact_retention_force: | >20N |
| contact_pin_material: | Beryllium Copper |
| dielectric_withstanding_voltage: | >750V |
| durability: | >500 cycles |
| function: | Male to Female RF Adapter |
| impedance: | 50Ohm |
| insulation_resistance: | >5000MOhm |
| insulator: | ULTEM 1000/PEI |
| max_operating_frequency: | 33GHz |
| max_operating_temperature: | +85°C |
| min_operating_frequency: | 0GHz |
| min_operating_temperature: | -40°C |
| thread_size: | M7x0.75 6g |
| uniek_nr: | blgRFAA240J350P |
| voltage_max: | 250V |
| vswr: | <1.15 |
