Splitter

The M12 Power H-splitter is a molded power connector designed for efficient power distribution with S-coded male and female connectors. It supports a 630 VAC rated voltage and a 12 A rated current, making it suitable for high-demand industrial applications. The splitter is built with a durable construction, utilizing materials like CuZn for the contacts and PA for the contact bearer. The TPU molded body ensures durability and long-term performance. This connector is designed for robust performance even in environments with operational temperatures ranging from -30°C to +90°C and offers reliable IP65, IP67, and IP68 protection degrees. The M12 Power H-splitter provides several advantages, including excellent electrical conductivity, high insulation resistance, and multiple mating cycles. Its compatibility with the Hirschmann/Lumberg Automation connector ensures secure and optimal connections in various industrial settings. The design and material choices make it resilient to physical and environmental stress, thereby extending its operational lifespan. This H-splitter is primarily used in industrial automation, machinery, and power distribution systems where dependable and robust connections are necessary. Its straightforward design facilitates easy installation and maintenance, making it suitable for a diverse range of applications.

The M12 Power H-splitter is a robust and efficient connector designed for power distribution in industrial applications. Featuring a male input and three female outputs, all L-coded and equipped with 4+FE pins, this splitter ensures secure and stable connections. The connector's H-shape design promotes efficient power distribution while maintaining compatibility with various M12 standards. Made from high-quality materials, including CuZn contact base, Cu/Au plating, and a PA contact bearer, this splitter offers excellent durability and corrosion resistance. It supports a rated voltage of 63 VDC and a current rating of 16 A, making it suitable for intensive industrial use. The protection rating up to IP68 ensures reliable operation in harsh environments. The benefits of the M12 Power H-splitter include its high durability, secure connections due to its high-quality construction, and compatibility with various industrial standards. Its L-coding provides clear and secure orientations during installations. This splitter is ideal for applications in industrial automation, machinery, and power distribution systems. It is especially useful in environments where space is limited and high reliability is essential.

The M12 Power H-splitter is an essential component for reliable and efficient power distribution in various industrial settings. Featuring a robust H-shaped design, this splitter includes male and female M12 connectors, each with 4 poles and T-coding for secure and accurate connections. It operates within an ambient temperature range of -30°C to +90°C, ensuring performance stability under varying conditions. With an IP rating up to IP68, it promises excellent resistance to dust and water, making it suitable for use in harsh environments. The connector is made from durable CuZn material with Cu/Au plating and TPU molded body, providing long-lasting durability and corrosion resistance. The M12 Power H-splitter is also RoHS compliant, ensuring it meets all safety and environmental standards.

The M12 Power h-splitter is a robust, high-performance connector designed for applications requiring reliable power distribution. Featuring a 4+FE configuration, both the male and female sides are equipped with L-coded M12 connectors. This splitter is capable of handling a rated voltage of 63 VDC and a rated current of 16 A, making it suitable for demanding industrial environments. The splitter is constructed from high-quality materials such as TPU for the molded body and CuZn for contact base materials, ensuring durability and efficient electrical transmission. Additionally, it is rated with IP65, IP67, and IP68 protection levels, guaranteeing optimal performance even in harsh conditions. The M12 Power h-splitter is an ideal solution for organizing and reliably distributing power in factory automation systems, industrial machinery, and other high-power applications.

The M12 Power T-splitter is equipped with a male straight, 4+PE K-coded M12 connector, and two female straight, 4+PE K-coded M12 connectors, making it a versatile solution for power signal splitting applications. Designed with durability in mind, it features a molded TPU body and gold-plated contacts to ensure a reliable and stable connection. With an impressive rated voltage of 630 VAC and a rated current of 12 A, this splitter is well-suited for high-power requirements. It offers exceptional protection with IP65, IP67, and IP68 ratings, and it can withstand operating temperatures from -30°C to +90°C, making it ideal for a wide range of industrial environments. The T-splitter adheres to IEC 61076-2-111 standards and is RoHS compliant, ensuring top-notch performance and safety.

The M12 Power h-splitter is designed for high-performance power distribution in industrial environments. It features one male, straight, 4-pole, T-coded M12 connector for input and two female, straight, 4-pole, T-coded M12 connectors for output. The connectors are made from CuZn with Cu/Au plating for optimal conductivity and durability. The housing is constructed from black TPU, ensuring robustness and longevity. The h-shaped design allows easy integration into existing systems while maintaining a high degree of protection with ratings of IP65, IP67, and IP68. This splitter operates within a temperature range of -30°C to +90°C, ensuring reliable performance under harsh conditions.

The M12 Power H-splitter is a robust and versatile connector designed for industrial automation and control systems. Featuring a male input and three female outputs, each with 4+PE pins and K-coding, this splitter ensures reliable power distribution in various settings. The H-shaped design and molded body, crafted from durable TPU and CuZn materials, offer excellent insulation resistance (≥10^8 Ohm) and can withstand harsh operating conditions with ambient temperatures ranging from -30°C to +90°C. Rated for 630 VAC and 12 A, this splitter also meets IEC 61076-2-111 standards and is RoHS compliant, ensuring high performance and safety. The splitter is IP65, IP67, and IP68 rated, providing superior protection against dust and water ingress. The M12 Power H-splitter’s benefits include efficient power management in complex systems, reduced installation time with its easy coupling nut attachment, and high durability, making it ideal for demanding environments. Applications for the M12 Power H-splitter span across various industrial sectors, including factory automation, robotics, and machinery where reliable power distribution and secure connections are critical.

The M12 Power T-splitter by Lumberg Automation serves as a rugged and reliable component for power distribution in harsh environments. With a male, straight, 4 poles, T-coded M12 input and dual female, straight, 4 poles, T-coded M12 outputs, it ensures secure and efficient connectivity. Rated for 63 VDC and 12 A, this T-splitter is designed from durable materials including CuZn base contacts with Cu/Au plating, ensuring robust performance. The molded body is crafted from TPU, providing excellent insulation and mechanical protection. Suitable for operating temperatures from -30°C to +90°C, it meets the standards of IEC 61076-2-111 and comes with a high insulation resistance of ≥10^8 Ohm. The splitter is RoHS compliant, affirming its alignment with environmental standards.

The M12 Power T-splitter is engineered for high-performance power distribution in industrial applications. This molded splitter features a 3+PE pin configuration and S-coding for secure connections. The male, straight M12 connector on the input side offers easy installation, while the two female, straight M12 connectors allow for versatile power sharing. Rated for 630 VAC and 12 A, this splitter ensures efficient power handling. It is built to withstand operational temperatures ranging from -30°C to +90°C, with a rugged construction compliant with IEC 61076-2-111 standards, guaranteeing durability in demanding environments. The T-splitter's contacts are made from CuZn with Cu/Au plating, housed in a TPU molded body, ensuring optimal conductivity and environmental protection.

The M12 Power h-splitter is a versatile and robust connector designed to facilitate power distribution in industrial automation systems. This splitter features a male, straight, 3+PE, S-coded M12 input and two female, straight, 3+PE, S-coded M12 outputs. With a rated voltage of 630 VAC (600 VAC UL) and a rated current of 12 A, this splitter is well-suited for demanding applications. The integration of high-quality materials like CuZn for the contact base, Cu/Au for the contact plating, and durable molded TPU body ensures reliability and long-term performance. It also offers protection ratings of IP65, IP67, and IP68, making it suitable for harsh environments. The M12 Power h-splitter is RoHS compliant, ensuring it meets environmental and safety regulations. Additionally, it operates efficiently within a temperature range of -30°C to +90°C, catering to a wide range of industrial settings.

M12 Power T-splitter: male, straight, 4+FE, L-coded, M12, female, straight, 4+FE, L-coded, M12, female, straight, 4+FE, L-coded
