7/8" Receptacle Female
RKF 20/11-03
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is a versatile and robust connector designed for a variety of high-power applications. This connector features a female, front mount design with 2 pins, housed in a durable silver casing. It operates at a rated voltage of 230 V AC/DC and a rated current of 12 A. The connector also ensures high reliability with a contact resistance of ≤ 10 mOhm and an insulation resistance of > 10^9 Ohm. Its materials, including CuZn contact base, Cu/Au contact plating, and a TPU contact bearer, make it sturdy and resistant to wear. The connector is suitable for use in environments with ambient temperatures ranging from -25 °C to +90 °C and has an IP68 protection rating, ensuring its performance under dust and water exposure.
€13.43
per item
RKF 40/11-02/1,7 M
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is a versatile female connector designed for front mount applications, featuring a robust 4-pin configuration. Enclosed in a silver housing, this connector is rated for a wide range of electrical uses with a voltage of 230 V AC/DC and a current rating up to 9 A. The connector ensures secure and reliable connections with its contact resistance of less than 10 mOhm and insulation resistance greater than 10^9 Ohm. It is equipped with four conductive wires, each with a 0.5 mm² cross-section, and is built for durability with a TPU contact bearer and neoprene sealing O-ring. The connector sustains a broad ambient temperature range from -25 °C to +90 °C, making it suitable for various industrial environments. It adheres to safety standards with an IP68 rating, ensuring protection against dust and water ingress, provided it is correctly mounted and locked.
€18.21
per item
RSF 60B-696/1F
1" Power Receptacle
1" Power Receptacle: Male, straight, 6-pin, front mount, 1/2" 14-NPT panel tap, 600 V, 8 A, 16 AWG, US Color Code
€92.17
per item
RKF 50/11-04
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is designed with a female, front mount configuration, featuring five pins (4+PE) and a robust silver housing. It operates at 230 V AC/DC and can handle a rated current of 9 A. The connector, with a conductor size of 0.50 mm² and unshielded design, is suitable for various industrial applications. Its CuZn contacts and nickel-plated housing ensure reliable performance and longevity. The connector complies with IP68 protection standards, ensuring its durability in harsh environments. This high-quality connector is RoHS compliant, making it a reliable choice for your power connection needs.
€17.97
per item
RKF 30/13,5-01
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is specifically designed for robust and reliable power transmission. This female connector features a front mount design and includes three pins (2+PE) housed in a durable silver casing. Rated for a maximum operating voltage of 230 V AC/DC and a current of 12 A, it is ideal for various power applications. The use of CuZn material with nickel plating ensures high conductivity and resistance to corrosion. Additionally, it complies with IP68 rating, offering protection against dust and water ingress. The connector is RoHS compliant, ensuring it meets the necessary environmental safety standards. The orange TPU material used for the contact bearer enhances the durability and operational temperature range of −25 °C to +90 °C. This connector is perfect for industrial applications requiring reliable power connections in harsh environments.
€15.28
per item
RKF 40/11-02
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is a robust and reliable solution for power connections. This female, front mount connector is equipped with 4 pins and constructed from high-quality materials, including a silver housing that is nickel-plated for enhanced durability. Rated for 230 V AC/DC and 9A, it’s suitable for a variety of industrial applications. The connector features a conductor size of 0.50 mm², ensuring optimal power transmission. Its IP68 rating ensures excellent protection against dust and water, making it ideal for harsh environments. Compliance with RoHS standards emphasizes its environmental friendliness. Perfect for integration in Lumberg Automation systems.
€16.23
per item
RKF 20/11-03/0,6 M
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is designed for high-performance applications, featuring a female receptacle, front mount design, and 2-pin configuration. With a robust silver housing, it operates efficiently at 230 V AC/DC and carries a load of up to 12 A. The connector accommodates a 0.75 mm² conductor size, ensuring reliable and secure electrical connections. It boasts an impressive insulation resistance of over 10^9 Ohm and a contact resistance of ≤ 10 mOhm. This connector is perfect for use in various industrial environments due to its IP68 rating, making it dust-tight and water-resistant.
€13.74
per item
RKF 50/13,5-04
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is a female, front mount connector designed by Lumberg Automation. It features a 5-pin (4+PE) configuration, operating at 230 V AC/DC with a current rating of 9 A. The housing is made of nickel-plated CuZn, providing enhanced durability and reliability. This product also meets the environmental compliance standards of RoHS. With an IP68 rating, it ensures protection against dust and water. Its construction uses high-quality materials like CuZn for contacts, Ni-plated CuZn for the housing, and TPU for contact bearers, which are orange in color. The connector supports conductors of size 0.5 mm² and can operate within a temperature range of -25 °C to +90 °C, making it suitable for various industrial applications.
€17.93
per item
RKF 40/13,5-02
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is a versatile and reliable solution for your power connection needs. Featuring a female, front mount design with four pins, this connector supports 230 V AC/DC and up to 9 A current. It is housed in a durable silver casing made of nickel-plated CuZn, ensuring long-lasting performance in various environments. The connector is unshielded with an ambient operating temperature range of -25°C to +90°C and an IP68 protection rating. This makes it suitable for a wide range of industrial applications. The conductor size is 0.50 mm², providing robust connectivity. Additionally, its compliance with RoHS ensures it meets high environmental and safety standards.
€16.23
per item
RKF 30/11-01
7/8" Power Receptacle Connector
The 7/8" Power Receptacle Connector is designed for robust and reliable power connections. This female, front mount connector with a 3-pin (2+PE) configuration ensures secure electrical connections. It features a durable silver housing and operates at 230 V AC/DC, handling up to 12 A of current. With a conductor size of 0.75 mm², it provides efficient conductivity. The connector adheres to IP68 protection standards, making it suitable for harsh environments. Ideal for industrial automation applications, this connector ensures optimal performance and safety with materials like CuZn for base contacts and nickel-plated housing.
€15.28
per item
